T40WPLUS HC LP Z22
T40W generates a great airflow and is the ideal tool to collect high quantities of very fine dust. The M and H class filters grant a safe dust containment.
Immediate delivery available
Immediate delivery on selected machines.
Anti Explosive Vacuum
ATEX Vacuum can work in zone 22-21-2 in compliance with directives 94/9/EC and 99/92/EC.
Filter Options
M class filter or with HEPA upstream or ULPA downstream absolute filter for the collection of very fine or hazardous dust.
T40WPLUS L100 LC Z22 EXA
40W generates a great airflow and is the ideal tool to collect high quantities of very fine dust. The M and H class filters grant a safe dust containment. The ATEX certification allows to work safely in explosion- proof areas.
Ideal to be used in companies producing high quantities of very fine dust, model T40WPlus is available in several configurations: with M class filter or with HEPA upstream or ULPA downstream absolute filter for the collection of very fine or hazardous dust, with cartridges filter and jet pulse cleaning system, with 50 or 100 liters container, with solid cut-off system and so on. ATEX versions can work in zone 22-21-2 in compliance with directives 94/9/EC and 99/92/EC.
Model No 4030800956
Voltage (V) 400
Frequency (Hz) 50
IP protection class 55
Insulation class F
Rated power (kW)4
Airflow without hose (m³/h – l/m) 489 – 8150
Max. vacuum (kPa – mbar) 19 – 190
Sound pressure level (dB(A)) 71
Container capacity (l) 100
Main filter area (cm²) 35000
Inlet (mm)70
Length x width x height (mm)1290x600x1640
